You are a system integrator or a user in the machine or plant construction sector or the like:. Information regarding purchasing the product, or a bespoke variation, is available on request. Able to restore normal operation after a power outage without user intervention.Ī variation has also been developed in the past to cope with slaves which do not use the standard Modbus protocol.
Diagnostic messages are available for the purposes of system fault finding.Traffic routing paths are displayed in an easily understood manner.Allows control of routing functions directly from the user interface or externally via Modbus registers.Stores and forwards all messages with a maximum delay of 100ms per message, even when running at 100% processor loading.Can handle message requests from up to 30 simultaneous connections without deviating from specified performance parameters.
13 RAZONES PORQUE SERIE COMPLETA EN ESPAÑOL SERIAL
Able to import and export slave and serial port settings for backup purposes. Configurable settings for all serial ports. Able to handle up to 254 unique Modbus slaves.
Freely user configurable for slave addressing and protocol type. Able to perform re-mapping of data from either single or multiple slaves into 'virtual slaves' to reduce polling requirements for master devices. Able to route messages from the Primary to the Backup Network and vice versa regardless of network addressing or subnets. Designed to route common Modbus functions (1,2,3,4,5,6,15 and 16), and can be modified to support other defined functions. Communicates with Modbus slaves using Modbus TCP or Modbus RTU-via-TCP (dependant on the slave type). Handles incoming Modbus RTU messages via any available serial port (up to a maximum of 255). Able to handle incoming Modbus TCP and Modbus RTU-via-TCP messages through either the Primary or Backup Ethernet ports. The register configuration and external slave setup is fully configurable by the user. The Virtual Slave will continually poll the external slave(s) setup within the user defined configuration and then transfer the retrieved data into registers held within the router. Re-maps data from either single or multiple slaves into 'virtual slaves' to reduce polling requirements for master devices Īnother useful feature is the ability to create 'virtual slaves' - these are entities created within the router to re-map data retrieved from a single or multiple external slaves into a more compact data map. Routes messages between two networks regardless of network addressing or subnets. Performs address translation on any slave to provide access to multiple slaves with the same ID connected to different sub networks. Communicates via multiple Modbus protocols (Modbus TCP, Modbus RTU and Modbus RTU-via-TCP). It supports both protocol and address translation, allowing seamless integration between multiple Modbus slaves and masters.
The Modbus Router is designed to provide a bridge between two separate control networks, allowing Modbus communications to pass through from one to the other based on an internal routing table, while the 2 networks remain separate (normal Ethernet traffic is not able to pass through the router).
